gVisor improves performance with root filesystem overlay

Overview

Container technology is an integral part of modern application ecosystems, making container security an increasingly important topic. Since containers are often used to run untrusted, potentially malicious code it is imperative to secure the host machine from the container.

A container's security depends on its security boundaries, such as user namespaces (which isolate security-related identifiers and attributes), seccomp rules (which restrict the syscalls available), and Linux Security Module configuration. Popular container management products like Docker and Kubernetes relax these and other security boundaries to increase usability, which means that users need additional container security tools to provide a much stronger isolation boundary between the container and the host.

The gVisor open source project, developed by Google, provides an OCI compatible container runtime called runsc. It is used in production at Google to run untrusted workloads securely. Runsc (run sandbox container) is compatible with Docker and Kubernetes and runs containers in a gVisor sandbox. gVisor sandbox has an application kernel, written in Golang, that implements a substantial portion of the Linux system call interface. All application syscalls are intercepted by the sandbox and handled in the user space kernel.

Although gVisor does not introduce large fixed overheads, sandboxing does add some performance overhead to certain workloads. gVisor has made several improvements recently that help containerized applications run faster inside the sandbox, including an improvement to the container root filesystem, which we will dive deeper into.

Costly Filesystem Access in gVisor

gVisor uses a trusted filesystem proxy process (“gofer”) to access the filesystem on behalf of the sandbox. The sandbox process is considered untrusted in gVisor’s security model. As a result, it is not given direct access to the container filesystem and its seccomp filters do not allow filesystem syscalls.

In gVisor, the container rootfs and bind mounts are configured to be served by a gofer.

Gofer mounts configuration in gVisor

When the container needs to perform a filesystem operation, it makes an RPC to the gofer which makes host system calls and services the RPC. This is quite expensive due to:

  1. RPC cost: This is the cost of communicating with the gofer process, including process scheduling, message serialization and IPC system calls.
    • To ameliorate this, gVisor recently developed a purpose-built protocol called LISAFS which is much more efficient than its predecessor.
    • gVisor is also experimenting with giving the sandbox direct access to the container filesystem in a secure manner. This would essentially nullify RPC costs as it avoids the gofer being in the critical path of filesystem operations.
  2. Syscall cost: This is the cost of making the host syscall which actually accesses/modifies the container filesystem. Syscalls are expensive, because they perform context switches into the kernel and back into userspace.
    • To help with this, gVisor heavily caches the filesystem tree in memory. So operations like stat(2) on cached files are serviced quickly. But other operations like mkdir(2) or rename(2) still need to make host syscalls.

Container Root Filesystem

In Docker and Kubernetes, the container’s root filesystem (rootfs) is based on the filesystem packaged with the image. The image’s filesystem is immutable. Any change a container makes to the rootfs is stored separately and is destroyed with the container. This way, the image’s filesystem can be shared efficiently with all containers running the same image. This is different from bind mounts, which allow containers to access the bound host filesystem tree. Changes to bind mounts are always propagated to the host and persist after the container exits.

Docker and Kubernetes both use the overlay filesystem by default to configure container rootfs. Overlayfs mounts are composed of one upper layer and multiple lower layers. The overlay filesystem presents a merged view of all these filesystem layers at its mount location and ensures that lower layers are read-only while all changes are held in the upper layer. The lower layer(s) constitute the “image layer” and the upper layer is the “container layer”. When the container is destroyed, the upper layer mount is destroyed as well, discarding the root filesystem changes the container may have made. Docker’s overlayfs driver documentation has a good explanation.

Rootfs Configuration Before

Let’s consider an example where the image has files foo and baz. The container overwrites foo and creates a new file bar. The diagram below shows how the root filesystem used to be configured in gVisor earlier. We used to go through the gofer and access/mutate the overlaid directory on the host. It also shows the state of the host overlay filesystem.

Rootfs configuration in gVisor earlier

Opportunity! Sandbox Internal Overlay

Given that the upper layer is destroyed with the container and that it is expensive to access/mutate a host filesystem from the sandbox, why keep the upper layer on the host at all? Instead we can move the upper layer into the sandbox.

The idea is to overlay the rootfs using a sandbox-internal overlay mount. We can use a tmpfs upper (container) layer and a read-only lower layer served by the gofer client. Any changes to rootfs would be held in tmpfs (in-memory). Accessing/mutating the upper layer would not require any gofer RPCs or syscalls to the host. This really speeds up filesystem operations on the upper layer, which contains newly created or copied-up files and directories.

Using the same example as above, the following diagram shows what the rootfs configuration would look like using a sandbox-internal overlay.

Rootfs configuration in gVisor with internal overlay

Host-Backed Overlay

The tmpfs mount by default will use the sandbox process’s memory to back all the file data in the mount. This can cause sandbox memory usage to blow up and exhaust the container’s memory limits, so it’s important to store all file data from tmpfs upper layer on disk. We need to have a tmpfs-backing “filestore” on the host filesystem. Using the example from above, this filestore on the host will store file data for foo and bar.

This would essentially flatten all regular files in tmpfs into one host file. The sandbox can mmap(2) the filestore into its address space. This allows it to access and mutate the filestore very efficiently, without incurring gofer RPCs or syscalls overheads.

Self-Backed Overlay

In Kubernetes, you can set local ephemeral storage limits. The upper layer of the rootfs overlay (writeable container layer) on the host contributes towards this limit. The kubelet enforces this limit by traversing the entire upper layer, stat(2)-ing all files and summing up their stat.st_blocks*block_size. If we move the upper layer into the sandbox, then the host upper layer is empty and the kubelet will not be able to enforce these limits.

To address this issue, we introduced “self-backed” overlays, which create the filestore in the host upper layer. This way, when the kubelet scans the host upper layer, the filestore will be detected and its stat.st_blocks should be representative of the total file usage in the sandbox-internal upper layer. It is also important to hide this filestore from the containerized application to avoid confusing it. We do so by creating a whiteout in the sandbox-internal upper layer, which blocks this file from appearing in the merged directory.

The following diagram shows what rootfs configuration would finally look like today in gVisor.

Rootfs configuration in gVisor with self-backed internal overlay

Performance Gains

Let’s look at some filesystem-intensive workloads to see how rootfs overlay impacts performance. These benchmarks were run on a gLinux desktop with KVM platform.

Micro Benchmark

Linux Test Project provides a fsstress binary. This program performs a large number of filesystem operations concurrently, creating and modifying a large filesystem tree of all sorts of files. We ran this program on the container's root filesystem. The exact usage was:

sh -c "mkdir /test && time fsstress -d /test -n 500 -p 20 -s 1680153482 -X -l 10"

You can use the -v flag (verbose mode) to see what filesystem operations are being performed.

The results were astounding! Rootfs overlay reduced the time to run this fsstress program from 262.79 seconds to 3.18 seconds! However, note that such microbenchmarks are not representative of real-world applications and we should not extrapolate these results to real-world performance.

Real-world Benchmark

Build jobs are very filesystem intensive workloads. They read a lot of source files, compile and write out binaries and object files. Let’s consider building the abseil-cpp project with bazel. Bazel performs a lot of filesystem operations in rootfs; in bazel’s cache located at ~/.cache/bazel/.

This is representative of the real-world because many other applications also use the container root filesystem as scratch space due to the handy property that it disappears on container exit. To make this more realistic, the abseil-cpp repo was attached to the container using a bind mount, which does not have an overlay.

When measuring performance, we care about reducing the sandboxing overhead and bringing gVisor performance as close as possible to unsandboxed performance. Sandboxing overhead can be calculated using the formula overhead = (s-n)/n where ‘s’ is the amount of time taken to run a workload inside gVisor sandbox and ‘n’ is the time taken to run the same workload natively (unsandboxed). The following graph shows that rootfs overlay halved the sandboxing overhead for abseil build!

The impact of rootfs overlay on sandboxing overhead for abseil build

Conclusion

Rootfs overlay in gVisor substantially improves performance for many filesystem-intensive workloads, so that developers no longer have to make large tradeoffs between performance and security. We recently made this optimization the default in runsc. This is part of our ongoing efforts to improve gVisor performance. You can learn more about gVisor at gvisor.dev. You can also use gVisor in GKE with GKE Sandbox. Happy sandboxing!

Explore the new Learn Kubernetes with Google website!

As Kubernetes has become a mainstream global technology, with 96% of organizations surveyed by the CNCF1 using or evaluating Kubernetes for production use, it is now estimated that 31%2 of backend developers worldwide are Kubernetes developers. To add to the growing popularity, the 2021 annual report1 also listed close to 60 enhancements by special interest and working groups to the Kubernetes project. With so much information in the ecosystem, how can Kubernetes developers stay on top of the latest developments and learn what to prioritize to best support their infrastructure?

The new website Learn Kubernetes with Google brings together under one roof the guidance of Kubernetes experts—both from Google and across the industry—to communicate the latest trends in building your Kubernetes infrastructure. You can access knowledge in two formats.

One option is to participate in scheduled live events, which consist of virtual panels that allow you to ask questions to experts via a Q&A forum. Virtual panels last for an hour, and happen once quarterly. So far, we’ve hosted panels on building a multi-cluster infrastructure, the Dockershim deprecation, bringing High Performance Computing (HPC) to Kuberntes, and securing your services with Istio on Kubernetes. The other option is to pick one of the multiple on-demand series available. Series are made up of several 5-10 minute episodes and you can go through them at your own leisure. They cover different topics, including the Kubernetes Gateway API, the MCS API, Batch workloads, and Getting started with Kubernetes. You can use the search bar on the top right side of the website to look up specific topics.
ALT TEXT
As the cloud native ecosystem becomes increasingly complex, this website will continue to offer evergreen content for Kubernetes developers and users. We recently launched a new content category for ecosystem projects, which started by covering how to run Istio on Kubernetes. Soon, we will also launch a content category for developer tools, starting with Minikube.

Join hundreds of developers that are already part of the Learn Kubernetes with Google community! Bookmark the website, sign up for an event today, and be sure to check back regularly for new content.

By María Cruz, Program Manager – Google Open Source Programs Office

  1. CNCF Annual Survey 2021 ↩

  2. The State of Cloud Native Development report by Slash Data, as cited on CNCF Annual Survey 2021 ↩

ko applies to become a CNCF sandbox project

Back in 2018, the team at Google working on Knative needed a faster way to iterate on Kubernetes controllers. They created a new tool dedicated to deploying Go applications to Kubernetes without having to worry about container images. That tool has proven to be indispensable to the Knative community, so in March 2019, Google released it as a stand-alone open source project named ko.

Since then, ko has gained in popularity as a simple, fast, and secure container image builder for Go applications. More recently, the ko community has added, amongst many other features, multi-platform support and automatic SBOM generation. Today, like the original team at Google, many open source and enterprise development teams depend on ko to improve their developer productivity. The ko project is also increasingly used as a solution for a number of build use-cases, and is being integrated into a variety of third party CI/CD tools.

At Google, we believe that using open source comes with a responsibility to contribute, sustain, and improve the projects that make our ecosystem better. To support the next phase of community-driven innovation, enable net-new adoption patterns, and to further raise the bar in the container tool industry, we are excited to announce today that we have submitted ko as a sandbox project to the Cloud Native Computing Foundation (CNCF).

This step begins the process of transferring the ko trademark, IP, and code to CNCF. We are excited to see how the broader open source community will continue innovating with ko.

By Mark Chmarny – Google Open Source Programs Office

Google Cloud & Kotlin GDE Kevin Davin helps others learn in the face of challenges

Posted by Kevin Hernandez, , Developer Relations Community Manager

Kevin Davin speaking at the SnowCamp Conference in 2019

Kevin Davin has always had a passion for learning and helping others learn, no matter their background or unique challenges they may face. He explains, “I want to learn something new every day, I want to help others learn, and I’m addicted to learning.” This mantra is evident in everything he does from giving talks at numerous conferences to helping people from underrepresented groups overcome imposter syndrome and even helping them become GDEs. In addition to learning, Kevin is also passionate about diversity and inclusion efforts, partly inspired by navigating the world with partial blindness.

Kevin has been a professional programmer for 10 years now and has been in the field of Computer Science for about 20 years. Through the years, he has emphasized the importance of learning how and where to learn. For example, while he learned a lot while he was studying at a university, he was able to learn just as much through his colleagues. In fact, it was through his colleagues that he picked up lessons in teamwork and the ability to learn from people with different points of view and experience. Since he was able to learn so much from those around him, Kevin also wanted to pay it forward and started volunteering at a school for people with disabilities. Guided by the Departmental Centers for People with Disabilities, the aim of the program is to teach coding languages and reintegrate students into a technical profession. During his time at this center, Kevin helped students practice what they learned and ultimately successfully transition into a new career.

During these experiences, Kevin was always involved in the developer community through open-source projects. It was through these projects that he learned about the GDE program and was connected to Google Developer advocates. Kevin was drawn to the GDE program because he wanted to share his knowledge with others and have direct access to Google in order to become an advocate on behalf of developers. In 2016, he discovered Kubernetes and helped his company at the time move to Google Cloud. He always felt like this model was the right solution and invested a lot of time to learn it and practice it. “Google Cloud is made for developers. It’s like a Lego set because you can take the parts you want and put it together,” he remarked.

The GDE program has given him access to the things he values most: being a part of a developer community, being an advocate for developers, helping people from all backgrounds feel included, and above all, an opportunity to learn something new every day. Kevin’s parting advice for hopeful GDEs is: “Even if you can’t reach the goal of being a GDE now, you can always get accepted in the future. Don’t be afraid to fail because without failure, you won’t learn anything.” With his involvement in the program, Kevin hopes to continue connecting with the developer community and learning while supporting diversity efforts.

Learn more about Kevin on Twitter & LinkedIn.

The Google Developer Experts (GDE) program is a global network of highly experienced technology experts, influencers, and thought leaders who actively support developers, companies, and tech communities by speaking at events and publishing content.

Gateway API Graduates to Beta

For many years, Kubernetes users have wanted more advanced routing capabilities to be configurable in a Kubernetes API. With Google leadership, Gateway API has been developed to dramatically increase the number of features available. This API enables many new features in Kubernetes, including traffic splitting, header modification, and forwarding traffic to backends in different namespaces, just to name a few.
Since the project was originally proposed, Googlers have helped lead the open source efforts. Two of the top contributors to the project are from Google, while more than 10 engineers from Google have contributed to the API.

This week, the API has graduated from alpha to beta. This marks a significant milestone in the API and reflects new-found stability. There are now over a dozen implementations of the API and many are passing a comprehensive set of conformance tests. This ensures that users will have a consistent experience when using this API, regardless of environment or underlying implementation.

A Simple Example

To highlight some of the new features this API enables, it may help to walk through an example. We’ll start with a Gateway:

apiVersion: gateway.networking.k8s.io/v1beta1

kind: Gateway

metadata:

  name: store-xlb

spec:

  gatewayClassName: gke-l7-gxlb

  listeners:

  - name: http

    protocol: HTTP

    port: 80
This Gateway uses the gke-l7-gxlb Gateway Class, which means a new external load balancer will be provisioned to serve this Gateway. Of course, we still need to tell the load balancer where to send traffic. We’ll use an HTTPRoute for this:

apiVersion: gateway.networking.k8s.io/v1beta1

kind: HTTPRoute

metadata:

  name: store

spec:

  parentRefs:

  - name: store-xlb

  rules:

  - matches:

    - path:

        type: PathPrefix

        value: /

    backendRefs:

    - name: store-svc

      port: 3080

      weight: 9

    - name: store-canary-svc

      port: 3080

      weight: 1
This simple HTTPRoute tells the load balancer to route traffic to one of the “store-svc” or “store-canary-svc” on port 3080. We’re using weights to do some basic traffic splitting here. That means that approximately 10% of requests will be routed to our canary Service.

Now, imagine that you want to provide a way for users to opt in or out of the canary service. To do that, we’ll add an additional HTTPRoute with some header matching configuration:

apiVersion: gateway.networking.k8s.io/v1beta1

kind: HTTPRoute

metadata:

  name: store-canary-option

spec:

  parentRefs:

  - name: store-xlb

  rules:

  - matches:

    - header:

        name: env

        value: stable

    backendRefs:

    - name: store-svc

      port: 3080

  - matches:

    - header:

        name: env

        value: canary

    backendRefs:

    - name: store-canary-svc

      port: 3080
This HTTPRoute works in conjunction with the first route we created. If any requests set the env header to “stable” or “canary” they’ll be routed directly to their preferred backend.

Getting Started

Unlike previous Kubernetes APIs, you don’t need to have the latest version of Kubernetes to use this API. Instead, this API is built with Custom Resource Definitions (CRDs) that can be installed in any Kubernetes cluster, as long as it is version 1.16 or newer (released almost 3 years ago).

To try this API on GKE, refer to the GKE specific installation instructions. Alternatively, if you’d like to use this API with another implementation, refer to the OSS getting started page.

What’s next for Gateway API?

As the core capabilities of Gateway API are stabilizing, new features and concepts are actively being explored. Ideas such as Route Delegation and a new GRPCRoute are deep in the design process. A new service mesh workstream has been established specifically to build consensus among mesh implementations for how this API can be used for service-to-service traffic. As with many open source projects, we’re trying to find the right balance between enabling new use cases and achieving API stability. This API has already accomplished a lot, but we’re most excited about what’s ahead.


By Rob Scott – GKE Networking

Server-side Apply in Kubernetes

What is Server-side Apply?

One of the highest velocity OSS projects of all time, Kubernetes is a cornerstone of Google’s cloud strategy. By providing an abstraction layer between users’ workloads and the underlying infrastructure, Kubernetes enables managing containerized workloads and services across--and migration from--both public cloud competitors and on-premise data centers.

In Config & Policy Automation (CPA) [1], in the Kubernetes Kernel team we aim to improve API expressiveness in Kubernetes so that more powerful controllers, tools, and UIs can be built using these APIs. The expressiveness and having better controllers, tools, and UIs are important to Google because they enable the ecosystem, and make it more sticky. It increases the ability to make more reliable systems that are simpler with better user experiences.

Bringing Server-side Apply to Kubernetes is one of the efforts led by Google to reduce fragmentation in clients, improve automation, and set Kubernetes up for ongoing success. Server-side Apply helps users and controllers manage their resources through declarative configurations. Clients can create and modify their objects declaratively by sending their fully specified intent. Server-side Apply replaces the client side apply feature implemented by “kubectl apply” with a Server-side implementation, permitting use by tools/clients other than kubectl (e.g. kpt). Server-side Apply is a new merging algorithm, as well as tracking of field ownership, running on the Kubernetes api-server. It enables new features like conflict detection, so the system knows when two actors are trying to edit the same field.

Server-side Apply Functionality

Since the Beta 2 release, subresources support has been added. Both client-go and Kubebuilder have added comprehensive support for Server-side Apply. This completes the Server-side Apply functionality required to make controller development practical.

Support for subresources

Server-side Apply now fully supports subresources like status and scale. This is particularly important for controllers, which are often responsible for writing to subresources.

Support in client-go

Previously, Server-side Apply could only be called from the client-go typed client using the Patch function, with PatchType set to ApplyPatchType. Now, Apply functions are included in the client to allow for a more direct and typesafe way of calling Server-side Apply. Each Apply function takes an "apply configuration" type as an argument, which is a structured representation of an Apply request.

Using Server-side Apply in a controller

You can use the new support for Server-side Apply no matter how you implemented your controller. However, the new client-go support makes it easier to use Server-side Apply in controllers.

When authoring new controllers to use Server-side Apply, a good approach is to have the controller recreate the apply configuration for an object each time it reconciles that object. This ensures that the controller fully reconciles all the fields that it is responsible for. Controllers typically should unconditionally set all the fields they own by setting Force: true in the ApplyOptions. Controllers must also provide a FieldManager name that is unique to the reconciliation loop that apply is called from.

When upgrading existing controllers to use Server-side Apply the same approach often works well--migrate the controllers to recreate the apply configuration each time it reconciles any object. Unfortunately, the controller might have multiple code paths that update different parts of an object depending on various conditions. Migrating a controller like this to Server-side Apply can be risky because if the controller forgets to include any fields in an apply configuration that is included in a previous apply request, a field can be accidentally deleted. To ease this type of migration, client-go apply support provides a way to replace any controller reconciliation code that performs a "read/modify-in-place/update" (or patch) workflow with a "extract/modify-in-place/apply" workflow.

Using Server-side Apply in CI/CD

Server-side Apply makes it easier to ensure that clusters can be safely transitioned to the state desired by new code changes as done by CI/CD systems. While CI/CD systems are highly specific to each team, a few general guidelines can help make the most out of this new functionality.

Once a code change results in new Kubernetes configurations (via whatever method the project uses to generate its Kubernetes configurations), the CI system can use server-side diff to present the developer and reviewer with details of what changes are being made as well as detecting any field ownership conflicts.

Developers can then iterate on field ownership conflicts until there are none left (or until the remaining conflicts are known and desired). Final approval can instruct the CD system to perform a Server-side Apply and either force conflicts to apply or instruct the system to block deployment on conflicts in case the cluster being deployed to has been modified in a way that creates new conflicts that the approver was previously unaware of.

Server-side Apply and CustomResourceDefinitions

It is strongly recommended that all Custom Resource Definitions (CRDs) have a schema. CRDs without a schema are treated as unstructured data by Server-side Apply. Keys are treated as fields in a struct and lists are assumed to be atomic. CRDs that specify a schema are able to specify additional annotations in the schema.

Server-side Apply Example

A simple example of an object created by Server-side Apply (SSA) could look like Fig. 1. The object contains a single manager in metadata.managedFields. The manager consists of basic information about the managing entity itself, like operation type, API version, and the fields managed by it. SSA uses a more declarative approach, which tracks a user's field management, rather than a user's last applied state. This means that as a side effect of using SSA, information about which field manager manages each field in an object also becomes available.

Fig 1. Server-side Apply Example
Fig 1. Server-side Apply Example

Server-side Apply use-cases in Google

Config Connector

Config Connector [3] leverages Server-side Apply to enable users to manage Google Cloud resources by both Config Connector and other configuration tools; e.g., gcloud, Cloud Console, or custom operators. Config Connector controllers use `managedFields` metadata to understand which fields are owned by Config Connector and which fields are managed outside the Kubernetes object [5]. Customers can have the flexibility of managing Google Cloud resources by both Config Connector and external tools; e.g., using a custom autoscaler for Bigtable clusters.

Config Sync

Config Sync [2] lets cluster operators and platform administrators deploy consistent configurations and policies, by continuously reconciling the state of clusters with Kubernetes configs stored in Git repositories. Config Sync leverages SSA to apply the configs to the clusters, and then monitors and remediates configuration drift using SSA.

KPT

KPT [4] is Git-native, schema-aware, extensible client-side tool for packaging, customizing, validating, and applying Kubernetes resources. KPT live apply leverages SSA to apply Kubernetes Resource Model (KRM) resources. It also uses SSA to preview the changes in KRM resources before applying them to the Kubernetes cluster.

What's Next?

After Server-side Apply, the next focus for the API Expression working-group is around improving the expressiveness and size of the published Kubernetes API schema. To see the full list of items we are working on, please join our working group and refer to the work items document.

How to get involved?

The working-group for apply is wg-api-expression. It is available on slack #wg-api-expression, through the mailing list.

References

[1] CPA: Config & Policy Automation: https://cloud.google.com/anthos/config-management
[2] Config Sync: https://cloud.google.com/anthos-config-management/docs/config-sync-overview
[3] Config Connector: https://cloud.google.com/config-connector/docs/overview
[4] KPT: https://opensource.google/projects/kpt
[5] Config Connector externally managed fields: https://cloud.google.com/config-connector/docs/concepts/managing-fields-externally


By Software Engineers- Antoine Pelisse, Joe Betz, Zeya Zhang, Janet Kuo, Kevin Delgado, Sunil Arora, and Engineering Manager, Leila Jalali




Four areas of open source contributions from Cloud Databases

Open Cloud enables you to develop software faster, innovate more easily, and scale more efficiently—while also reducing technology risk. Google has a long history of leadership in open source, and today, I want to look back at our activities around open source projects, for databases, over the past year.

Give developers the best tools to be efficient

Developers choose to build applications with managed database services on Google Cloud to benefit from velocity, scalability, security, and performance. To enable you to be most efficient and deliver your best possible work, we deliver tools and frameworks that work with your preferred development environments, no matter if you develop in the cloud or on premises. To make local testing, building and continuous integration easier for our cloud-native databases, we released emulators for Cloud Spanner, Firestore, and Cloud Bigtable so that you can test your code wherever you develop it - without the need to create or re-create cloud infrastructure with every test run.

Another area where we are helping developers is with instrumentation of Cloud SQL for easier debugging and performance tuning. With Cloud SQL Insights it is easier than ever to pinpoint underperforming SQL statements. That said, without additional instrumentation, it can be cumbersome to identify the source code or microservice that issued that SQL - let alone tying a SQL statement to a client session and its context. So we released Sqlcommenter as an open source library that will automatically add this instrumentation as SQL comments in queries that are generated by popular ORMs like Hibernate, Django, Sqlalchemy, and others (repo blog). We didn’t stop there, but merged Sqlcommenter with OpenTelemetry (blog) to add SQL insights from instrumented queries back to OpenTelemetry traces.

Lastly, we want to broaden access to our differentiated offerings, like Spanner. The recently announced Spanner PostgreSQL interface allows organizations to access Spanner’s industry-leading consistency and availability at scale using tools and skills from the popular PostgreSQL ecosystem. This new way of working with Spanner provides familiarity for developers and portability for administrators. (blog) Learn more in the documentation or sign up for the preview today.

Provide connectivity that is simple and secure

Connecting to APIs and databases from an application running in the cloud should be simple and secure. That’s why we recommend using IAM and Application Default Credentials when authenticating to other services. The Cloud SQL Proxy (repo) has been doing this and also setting up firewalls for you for a while. It works by running a local client either inside your VM or a GKE cluster. This year, we added libraries for Java (repo) and Python (repo) that can provide similar functionality without the overhead of running an extra client such as the proxy.

Cloud Spanner also offers an open source adapter for its new PostgreSQL interface (repo). This local proxy allows tools, starting with psql, to connect to a Spanner database using the PostgreSQL wire protocol.

Image 1: White pipes in datacenter

Manage cloud infrastructure with the tools of your choice

When it comes to provisioning, monitoring, and managing your cloud database services, flexibility and choice are important. We provide you with our cloud console, gcloud cli, and APIs as well as our own Deployment Manager. That said, you may prefer different ways to manage cloud infrastructure - whether through interactive tools or scripts or embedded into CI/CD pipelines that support GitOps or other controls, checks, and balances. Terraform is one of those open tools that is very popular - and we ensure that our cloud databases can be managed from it as documented in this blog about creating Spanner instances with Terraform.

If you manage the majority of your resources with Kubernetes either directly or through package managers like Helm, then our Kubernetes Config Connector (KCC) might be for you. In a nutshell, KCC exposes Google Cloud services such as Cloud SQL, Spanner, and others as Custom Resources in Kubernetes. This allows you to create and reconcile cloud resources outside of Kubernetes just like K8s native objects.

Once you are managing cloud infrastructure with CI/CD, the next step is to extend that same mechanism to manage objects within your databases such as tables, indexes, and views. To that extent we have released a Liquibase extension for Cloud Spanner.

Help you to move data with confidence

Cloud journeys often involve moving data either in a lift and shift process or sometimes replatforming to a different database. Whatever your journey, we want to simplify the process and give you the confidence that your migration is successful.

For enterprise users with Oracle databases, we have several open source projects. First, we have the Optimus Prime database assessment tool (repo) that queries your database and collects information about schemas and historic performance to be analyzed for migration complexity and consolidation potential. Our own professional services teams have been using this toolset to plan migrations to Bare Metal Solution for Oracle.

Some Oracle users are looking for opportunities to transform their workloads to fit with their bigger strategy of modernizing applications with Kubernetes. For this group we developed and open sourced the El Carro Kubernetes operator for Oracle. This not only automates database lifecycle tasks for systems running on Kubernetes, but also exposes declarative APIs for these operations.

If your application supports replatforming from Oracle to PostgreSQL, then we have a toolset for schema conversion along with dataflow pipelines that will read the output of a change data capture job and load it into a PostgreSQL database. What a great use-case for Datastream - our new serverless change data capture service.

Another case of heterogeneous database migration is to move MySQL or PostgreSQL databases to Cloud Spanner. HarbourBridge helps with the evaluation and data migration, and our latest contribution was adding support for DynamoDB as a source database. Part of every heterogeneous migration should be to validate that the source and target data are matching - we have released the Data Validation Toolkit for that use-case. DVT can connect to a number of source and target databases and compare the data on each side - giving you the confidence that your migration did not miss or change any records.

Conclusion

Whether you are migrating existing databases or you are building your next application in the cloud - we want to make your journey as comfortable and seamless as possible. Open source projects play a big role in meeting you where you are and providing you with the connectivity options, language support, and tools you want for management and migrations.

By Bjoern Rost, Product Manager, Google Cloud Databases

Learn Kubernetes with Google: Join us live on October 6!



Graphic describing the Multi-cluster Services API functionalities

Kubernetes hasn’t stopped growing since it was released by Google as an open source project back in June 2014: from July 7, 2020 to a year later in 2021, there were 2,284 new contributors to the project1. And that’s not all: in 2020 alone, the Kubernetes project had 35 stable graduations2. These are 35 new features that are ready for production use in a Kubernetes environment. Looking at the CNCF Survey 2020, use of Kubernetes has increased to 83%, up from 78% in 2019. With these many new people joining the community, and the project gaining so much complexity: how can we make sure that Kubernetes remains accessible to everyone, including newcomers?

This is the question that inspired the creation of Learn Kubernetes with Google, a content program where we develop resources that explain how to make Kubernetes work best for you. At the Google Open Source Programs Office, we believe that increasing access for everyone starts by democratizing knowledge. This is why we started with a series of short videos that focus on specific Kubernetes topics, like the Gateway API, Migrating from Dockershim to Containerd, the Horizontal Pod Autoscaler, and many more topics!

Join us live

On October 6, 2021, we are launching a series of live events where you can interact live with Kubernetes experts from across the industry and ask questions—register now and join for free! “Think beyond the cluster: Multi-cluster support on Kubernetes” is a live panel that brings together the following experts:
  • Laura Lorenz - Software Engineer (Google) / Member of SIG Multicluster in the Kubernetes project
  • Tim Hockin - Software Engineer (Google) / Co-Chair of SIG Network in the Kubernetes project
  • Jeremy Olmsted-Thompson - Sr Staff software Engineer (Google) / Co-Chair of the SIG Multicluster in the Kubernetes project
  • Ricardo Rocha - Computing Engineer (CERN) / TOC Member at the CNCF
  • Paul Morie - Software Engineer (Apple) / Co-Chair of the SIG Multicluster in the Kubernetes project
Why is Multi-cluster support in Kubernetes important? Kubernetes has brought a unified method of managing applications and their infrastructure. Engineering your application to be a global service requires that you start thinking beyond a single cluster; yet, there are many challenges when deploying multiple clusters at a global scale. Multi-cluster has many advantages, it lets you minimize the latency and optimize it for the people consuming your application.

In this panel, we will review the history behind multi-cluster, why you should use it, how companies are deploying multi-cluster, and what are some efforts in upstream Kubernetes that are enabling it today. Check out the “Resources” tab on the event page to learn more about the Kubernetes MCS API and Join us on Oct 6!

By María Cruz, Program Manager – Google Open Source Programs Office

1 According to devstats

2 Kubernetes Community Annual Report 2020

El Carro extends the flexibility and choices for Oracle databases on Kubernetes

When we released El Carro, our goal was to provide the best experience possible to run Oracle databases on Kubernetes with the help of our operator. Today, we want to take a closer look at how that works. The diagram below shows the high-level architecture of a database that is managed by El Carro. At the core is the actual database instance with its background processes which run in a single container that contains the Oracle installation. So how does this container image get created and what goes into it? The image itself is essentially a snapshot of a filesystem that contains an operating system, packages and other software, and custom scripts. Specifically for El Carro, an image is made up of a base OS, required packages, and an Oracle database installation. The image must be stored on a container registry that is accessible by the Kubernetes cluster, and El Carro will expect oracle binaries to be installed in certain paths—or create symbolic links to those locations.

Architecture Diagram showing the operator controlling the db container.

Initially, El Carro worked with 12c for Enterprise Edition and 18c for Express Edition. And while 12c is still popular with many users, the extended support ended this summer. So the first news is that we added support for 19c, Oracle’s long term release. The choice should be easy for any new database deployments, but the options don’t end there.

We know that DBAs have different preferences in how and where software gets installed and we believe that making different options available will ultimately empower users. With the exception of Express Edition, redistributing is not a right granted by Oracle licenses, preventing the community from providing a public container registry with usable images. Rather than that, each user will have to build their own image based on binaries they download from Oracle themselves, using their own license agreement with Oracle. All of the other containers used by the El Carro operator use open source software and are made available on our public registry, so that you do not have to build and host them yourself.

Option 1 - Use El Carro to build your own image with GCP

If you are using GCP, then we have an easy way for you to create custom images, you just upload Oracle binaries and patches to your own GCS bucket and start a Cloud Build job that will create the container image for you and upload it to your own, private container registry. A single build script and serverless cloud services take care of the whole process, so that you don’t have to worry about building locally and moving more images across the internet. In addition to creating seeded images (see below), this method also allows you to build containers with the Oracle Patches such as Release Update Revisions (RURs).

Diagram of container image build pipeline where a cloud build job reads installation files from GCS and writes finished images to GCR.

Option 2 - Use El Carro to build you own image locally

You can also use the same Dockerfile and build process from Option 1—but without Google Cloud. Download Oracle installers and patches locally or to a VM used for the builds—then start a script that invokes Docker and builds the image on that machine. Lastly, tag and push the container image to a container registry of your choice. You will have to do a few more steps yourself if you don’t use Cloud Build, but you get the same image and customization options as with Option 1.

Option 3 - Use Oracle build scripts to build your own image

Oracle also maintains an open source repository of scripts to build container images with their database. Maybe you are already using those images either with docker or Kubernetes, or you prefer to use Oracle’s own build method over ours. We recently added functionality to El Carro to make sure that the resulting images work just as well as the ones that El Carro can build for you.

Option 4 - Use Oracle’s Container Registry directly

There is a way to avoid building your own images: The Oracle Container Registry contains pre-built images that can be used with our Kubernetes operator directly and without modification. But since Oracle’s registry can only be accessed by customers, it is protected with a password. After accepting Oracle’s license conditions, one can either copy images to their own registry, or configure OCR as a private repository in Kubernetes.

The Power of Seeding

Aside from the installation, it is the creation of a database that takes the longest time in the initial provisioning process and it is often a frustrating wait time before you can log in and use your database for the first time after creation. To reduce this wait time, the first two options allow you to build a pre-seeded database image that already contains a snapshot of a created and configured database. That way this initialization step is moved to the container build process and minimizes the startup time of new database instances.

Aside from the wait time, relying on a seeded image (i.e. including an empty database in the image can provide consistency in config options if the same image is to be used in multiple deployments).

Option 1 - El Carro on GCP

Option 2 - El Carro local build

Option 3 - Oracle local build

Option 4 - Oracle Container Registry

Versions

12c, 18c, 19c

12c, 18c, 19c

12c, 18c, 19c

19c

Editions

XE, EE

XE, EE

EE

EE

Patches Updates

yes

yes

no

no

Seeded Images

yes

yes

no

no

Automatic build pipeline

yes

no

no

n/a

Conclusion

We believe in an open cloud approach and empowering users with choice and flexibility. In the context of running Oracle databases on Kubernetes that means that you get to choose your database container images. El Carro provides build scripts that allow you to not only customize containers but also to increase security and robustness with the ability to bake patches and updates into the container image. Seeding container images with a database further reduces the deployment time by avoiding this step on first startup - which is especially useful in environments that create many databases - such as automatic test pipelines.

But other users may feel more comfortable in receiving support when they use Oracle’s pre-built images from their registry.

The choice is yours. Just know that El Carro is here to help you modernize your Oracle database workloads with Kubernetes. And if you have any other feature requests or choices that matter to you—let us know by filing an issue on Github.

By Bjoern Rost, Product Manager and Ash Gbadamassi, Software Engineer – Cloud Databases

Verifiable Supply Chain Metadata for Tekton

Posted by Dan Lorenc, Priya Wadhwa, Open Source Security Team

If you've been paying attention to the news at all lately, you've probably noticed that software supply chain attacks are rapidly becoming a big problem. Whether you're trying to prevent these attacks, responding to an ongoing one or recovering from one, you understand that knowing what is happening in your CI/CD pipeline is critical.

Fortunately, the Kubernetes-native Tekton project – an open-source framework for creating CI/CD systems – was designed with security in mind from Day One, and the new Tekton Chains project is here to help take it to the next level. Tekton Chains securely captures metadata for CI/CD pipeline executions. We made two really important design decisions early on in Tekton that make supply chain security easy: declarative pipeline definitions and explicit state transitions. This next section will explain what these mean in practice and how they make it easy to build a secure delivery pipeline.


Definitions or “boxes and arrows”
Just like everything in your high school physics class, a CI/CD pipeline can be modeled as a series of boxes. Each box has some inputs, some outputs, and some steps that happen in the middle. Even if you have one big complicated bash script that fetches dependencies, builds programs, runs tests, downloads the internet and deploys to production, you can draw boxes and arrows to represent this flow. The boxes might be really big, but you can do it.

Since the initial whiteboard sketches, the Pipeline and Task CRDs in Tekton were designed to allow users to define each step of their pipeline at a granular level. These types include support for mandatory declared inputs, outputs, and build environments. This means you can track exactly what sources went into a build, what tools were used during the build itself and what artifacts came out at the end. By breaking up a large monolithic pipeline into a series of smaller, reusable steps, you can increase visibility into the overall system. This makes it easier to understand your exposure to supply chain attacks, detect issues when they do happen and recover from them after.


Explicit transitions
After a pipeline is defined, there are a few approaches to orchestrating it: level-triggered and edge-triggered. Like most of the Kubernetes ecosystem, Tekton is designed to operate in a level-triggered fashion. This means steps are executed explicitly by a central orchestrator which runs one task, waits for completion, then decides what to do next. In edge-based systems, a pipeline definition would be translated into a set of events and listeners. Each step fires off events when it completes, and these events are then picked up by listeners which run the next set of steps.

Event-based or edge-triggered systems are easy to reason about, but can be tricky to manage at scale. They also make it much harder to track an artifact as it flows through the entire system. Each step in the pipeline only knows about the one immediately before it; no step is responsible for tracking the entire execution. This can become problematic when you try to understand the security posture of your delivery pipeline.

Tekton was designed with the opposite approach in mind - level-triggered. Instead of a Rube-Goldberg machine tied together with duct tape and clothespins, Tekton is more like an explicit assembly-line. Level-triggered systems like Tekton move from state-to-state in a calculated manner by a central orchestrator. They require more explicit-design up front, but they are easier to observe and reason about after. Supply chains that use systems like Tekton are more secure.


Secure delivery pipeline through chains and provenance
So how do these two design decisions combine to make supply chain security easier? Enter Tekton Chains.

By observing the execution of a Task or a Pipeline and paying careful attention to the inputs, outputs, and steps along the way, we can make it easier to track down what happened and why later on. This "observer" can be run in a separate trust domain and cryptographically sign all of this captured metadata as it's stored, leaving a tamper-proof activity ledger. This technique is called "verifiable builds." This securely generated metadata can be used in a number of ways, from audit logging to recovering from security breaches to pre-deployment policy enforcement.

You can install Chains into any Tekton-enabled cluster and configure it to generate this cryptographically-signed supply chain metadata for your builds. Chains supports pluggable signature systems like PGP, x509 and Cloud KMS's. Payloads can be generated in a few different industry-standard formats like the RedHat Simple-Signing and the In-Toto Provenance specifications. The full documentation is available here, but you can get started quickly with something like this:


For this tutorial, you’ll need access to a GKE Kubernetes cluster and a GCR registry with push credentials. The cluster should already have Tekton Pipelines installed.


Install Tekton Chains into your cluster:

$ kubectl apply --filename https://storage.googleapis.com/tekton-releases/chains/latest/release.yaml



Next, you’ll set up registry authentication for the Tekton Chains controller, so that it can push OCI image signatures to your registry. To set up authentication, you’ll create a Service Account and download credentials:

$ export PROJECT_ID=<GCP Project ID>

$ gcloud iam service-accounts create tekton-chains

$ gcloud iam service-accounts keys create credentials.json --iam-account=tekton-chains@${PROJECT_ID}.iam.gserviceaccount.com



Now, create a Kubernetes Secret from your credentials file so the Chains controller can access it:

$ kubectl create secret docker-registry registry-credentials \

  --docker-server=gcr.io \

  --docker-username=_json_key \

  [email protected] \

  --docker-password="$(cat credentials.json)" \

  -n tekton-chains

$ kubectl patch serviceaccount tekton-chains-controller \

  -p "{\"imagePullSecrets\": [{\"name\": \"registry-credentials\"}]}" -n tekton-chains



We can use cosign to generate a keypair as a Kubernetes secret, which the Chains controller will use for signing. Cosign will ask for a password, which will be stored in the secret:

$ cosign generate-key-pair -k8s tekton-chains/signing-secrets


Next, you’ll need to set up authentication to your GCR registry for the kaniko task as another Kubernetes Secret.

$ export CREDENTIALS_SECRET=kaniko-credentials

$ kubectl create secret generic $CREDENTIALS_SECRET --from-file credentials.json



Now, we’ll create a kaniko-chains task which will build and push a container image to your registry. Tekton Chains will recognize that an image has been built, and sign it automatically.

$ kubectl apply -f https://raw.githubusercontent.com/tektoncd/chains/main/examples/kaniko/gcp/kaniko.yaml

$ cat <<EOF | kubectl apply -f -

apiVersion: tekton.dev/v1beta1

kind: TaskRun

metadata:

  name: kaniko-run

spec:

  taskRef:

    name: kaniko-gcp

  params:

  - name: IMAGE

    value: gcr.io/${PROJECT_ID}/kaniko-chains

  workspaces:

  - name: source

    emptyDir: {}

  - name: credentials

    secret:

      secretName: ${CREDENTIALS_SECRET}

EOF



Wait for the TaskRun to complete, and give the Tekton Chains controller a few seconds to sign the image and store the signature. You should be able to verify the signature with cosign and your public key:

$ cosign verify -key cosign.pub gcr.io/${PROJECT_ID}/kaniko-chains


Congratulations! You’ve successfully signed and verified an OCI image with Tekton Chains and cosign.


What's Next
Within Chains, we'll be improving integration with other supply-chain security projects. This includes support for Binary Transparency and Verifiable Builds through integrations with the Sigstore and In-Toto projects. We'll also be improving and providing a set of well-designed, highly secure Tasks and Pipeline definitions in the TektonCD Catalog.

In Tekton Pipelines, we plan on finishing up TEP-0025 (Hermekton) to enable the support for hermetic build execution. If you want to play around with it now, hermekton can be run as an alpha feature in experimental mode. When hermekton is enabled, a build runs in a locked-down environment without network connectivity. Hermetic builds guarantee all inputs have been explicitly declared ahead-of-time, providing for a more auditable supply-chain. Hermetic builds and Chains align well, because the hermeticity build property is contained in the full build provenance captured by Chains. Chains can generate and attest to metadata specifying exactly which sections of a build had network access.

This means policy can be defined around exactly which build tools are allowed to access the network and which ones are not. This metadata can be used in policies at build time (banning compilers with security vulnerabilities) or stored and used by policy engines at deploy time (only code-reviewed and verifiably built containers are allowed to run).

We believe supply-chain security must be built-in and by default. No task orchestrator can promise perfect supply-chain security, but TektonCD was designed with unique features in mind that make it easier to do the right thing. We're always looking for feedback on the design, goals and requirements. You can reach out on GitHub or the #chains Slack channel.
