Google is constantly working to improve our systems that protect users from Potentially Harmful Applications (PHAs). Usually, PHA authors attempt to install their harmful apps on as many devices as possible. However, a few PHA authors spend substantial effort, time, and money to create and install their harmful app on one or a very small number of devices. This is known as a targeted attack.
In this blog post, we describe Chrysaor, a newly discovered family of spyware that was used in a targeted attack on a small number of Android devices, and how investigations like this help Google protect Android users from a variety of threats.
What is Chrysaor?
Chrysaor is spyware believed to be created by NSO Group Technologies, specializing in the creation and sale of software and infrastructure for targeted attacks. Chrysaor is believed to be related to the Pegasus spyware that was first identified on iOS and analyzed by Citizen Lab and Lookout.
Late last year, after receiving a list of suspicious package names from Lookout, we discovered that a few dozen Android devices may have installed an application related to Pegasus, which we named Chrysaor. Although the applications were never available in Google Play, we immediately identified the scope of the problem by using Verify Apps. We gathered information from affected devices, and concurrently, attempted to acquire Chrysaor apps to better understand its impact on users. We’ve contacted the potentially affected users, disabled the applications on affected devices, and implemented changes in Verify Apps to protect all users.
What is the scope of Chrysaor?
Chrysaor was never available in Google Play and had a very low volume of installs outside of Google Play. Among the over 1.4 billion devices protected by Verify Apps, we observed fewer than 3 dozen installs of Chrysaor on victim devices. These devices were located in the following countries:
How we protect you
To protect Android devices and users, Google Play provides a complete set of security services that update outside of platform releases. Users don’t have to install any additional security services to keep their devices safe. In 2016, these services protected over 1.4 billion devices, making Google one of the largest providers of on-device security services in the world:
- Identify PHAs using people, systems in the cloud, and data sent to us from devices
- Warn users about or blocking users from installing PHAs
- Continually scan devices for PHAs and other harmful threats
What do I need to do?
It is extremely unlikely you or someone you know was affected by Chrysaor malware. Through our investigation, we identified less than 3 dozen devices affected by Chrysaor, we have disabled Chrysaor on those devices, and we have notified users of all known affected devices. Additionally, the improvements we made to our protections have been enabled for all users of our security services.
To ensure you are fully protected against PHAs and other threats, we recommend these 5 basic steps:
- Install apps only from reputable sources: Install apps from a reputable source, such as Google Play. No Chrysaor apps were on Google Play.
- Enable a secure lock screen: Pick a PIN, pattern, or password that is easy for you to remember and hard for others to guess.
- Update your device: Keep your device up-to-date with the latest security patches.
- Verify Apps: Ensure Verify Apps is enabled.
- Locate your device: Practice finding your device with Android Device Manager because you are far more likely to lose your device than install a PHA.
To install Chrysaor, we believe an attacker coaxed specifically targeted individuals to download the malicious software onto their device. Once Chrysaor is installed, a remote operator is able to surveil the victim’s activities on the device and within the vicinity, leveraging microphone, camera, data collection, and logging and tracking application activities on communication apps such as phone and SMS.
One representative sample Chrysaor app that we analyzed was tailored to devices running Jellybean (4.3) or earlier. The following is a review of scope and impact of the Chrysaor app named com.network.android tailored for a Samsung device target, with SHA256 digest:
ade8bef0ac29fa363fc9afd958af0074478aef650adeb0318517b48bd996d5d5
Upon installation, the app uses known framaroot exploits to escalate privileges and break Android’s application sandbox. If the targeted device is not vulnerable to these exploits, then the app attempts to use a superuser binary pre-positioned at /system/csk to elevate privileges.
After escalating privileges, the app immediately protects itself and starts to collect data, by:
- Installing itself on the /system partition to persist across factory resets
- Removing Samsung’s system update app (com.sec.android.fotaclient) and disabling auto-updates to maintain persistence (sets Settings.System.SOFTWARE_UPDATE_AUTO_UPDATE to 0)
- Deleting WAP push messages and changing WAP message settings, possibly for anti-forensic purpose.
- Starting content observers and the main task loop to receive remote commands and exfiltrate data.
- Repeated commands: use alarms to periodically repeat actions on the device to expose data, including gathering location data.
- Data collectors: dump all existing content on the device into a queue. Data collectors are used in conjunction with repeated commands to collect user data including, SMS settings, SMS messages, Call logs, Browser History, Calendar, Contacts, Emails, and messages from selected messaging apps, including WhatsApp, Twitter, Facebook, Kakoa, Viber, and Skype by making /data/data directories of the apps world readable.
- Content observers: use Android’s ContentObserver framework to gather changes in SMS, Calendar, Contacts, Cell info, Email, WhatsApp, Facebook, Twitter, Kakao, Viber, and Skype.
- Screenshots: captures an image of the current screen via the raw frame buffer.
- Keylogging: record input events by hooking IPCThreadState::Transact from /system/lib/libbinder.so, and intercepting android::parcel with the interface com.android.internal.view.IInputContext.
- RoomTap: silently answers a telephone call and stays connected in the background, allowing the caller to hear conversations within the range of the phone's microphone. If the user unlocks their device, they will see a black screen while the app drops the call, resets call settings and prepares for the user to interact with the device normally.
- Via a command from the server
- Autoremove if the device has not been able to check in to the server after 60 days
- Via an antidote file. If /sdcard/MemosForNotes was present on the device, the Chrysaor app removes itself from the device.
To encourage further research in the security community, we’ve uploaded these sample Chrysaor apps to Virus Total.
Additional digests with links to Chrysaor
As a result of our investigation we have identified these additional Chrysaor-related apps.
Lookout has completed their own independent analysis of the samples we acquired, their report can be viewed here.
